| Power: |
8x |
10x |
| Objective Lens: |
42mm |
42mm |
| Field of View: |
429ft @ 1000yds, 143M @ 1000M (8.17º) |
342ft @ 1000yds, 113M @ 1000M (6.5º) |
| Prism Type: |
Phase Coated Bak4 Roof Prism |
Phase Coated Bak4 Roof Prism |
| Lens Coating: |
Fully Multi-Coated |
Fully Multi-Coated |
| Waterproof Rating: |
IPX7 - 30 min under 1M water |
IPX7 - 30 min under 1M water |
| Fogproofing: |
Nitrogen filled, sealed O-rings |
Nitrogen filled, sealed O-rings |
| Diopter System: |
±4º, Right Eye |
±4º, Right Eye |
| Eye Cups: |
Multi Stop Twist Up |
Multi Stop Twist Up |
| Number of Lenses: |
8 pieces / 6 groups (per side) |
8 pieces / 6 groups (per side) |
| Close Focus: |
2M (6ft) |
2M (6ft) |
| Dimensions: |
145x129mm, 5.7” x 5.07” |
145x129mm, 5.7” x 5.07” |
| Height: |
55mm, 2.16” |
55mm, 2.16” |
| Weight: |
680g, 1.5lb |
680g, 1.5lb |
| Eye Relief: |
17mm |
15mm |
| Relative Brightness: |
27.04 |
18.23 |
| Exit Pupil Diameter: |
5.25mm |
4.20mm |
| Interpupillary Distance: |
55mm - 73mm |
55mm - 73mm |
| Tripod Compatibility: |
Yes |
